The seven operation methods of high speed door

1. Motion sensor /radar sensor: when the radar detects a moving object or pedestrian, the door will open quickly and automatically shut down and fall back to the set delay time.

2. Remote control: the PVC High Speed Door can be controlled by remote control, the remotes working distance can be up to 20m, there’s open, close , stop and lock 4 buttons on the transmitter.

3. Manual pull cord switch: people can gently pull the manual rope, the door will be opened quickly automatically, and then it will fall after a set time delay.

4. Geomagnetic sensor: when a metal object, such as a vehicle, the magnetic field is measured after inspection, and the door will be opened quickly and then close as per the preset time.

5. Airbag sensor/safety edge sensor: when the bottom of the rapid rolling door with high-pressure air body side door feels, the volume of successful transaction decreases. During the high-speed process, it drops to the bottom of the door. The rapid door will be stop and reverse back when it senses people or object during the door is closing, for the purpose of protection.

6. Push button: the wall mounted push button is easy to install on wall, and convenient for operations of door open & close.

7. Interlocking device: when the logistics vehicle enters a certain gate, one door opens, but the other door at the other end of the passage cannot be opened. The other gate can only be opened after the logistics vehicle enters the buffer area and the entry door is automatically closed. The function is called electronic interlocking function, which has many applications in the purification industry. The industrial fast doors manufactured by the ideal door industry have this function.
