Hong fa Doors with PVC Curtain

Dive into the future of office chic with the Hong Fa PVC Curtain Door—a revolutionary blend of style and practicality! Perfect for the modern professional, this door doesn’t just swing open; it sways like a graceful curtain. Ideal for those who want to make an entrance without making noise. Keep the office chatter in or out with the flick of a wrist. Available in a spectrum of colors to match your personality and office decor. Because why have a boring door when you can have a fashion statement that swings both ways?

High speed rolling door

1.Control systems

The control system can keep the door run very steady. And there will be little spoilage even the door is used frequently everyday.

2.Dynamical systems

Adopt special high-speed motor reducer, 0.75-2.2KW, the model is selected according to different door size.

Brand: SEW

3. High Speed Rolling Door Construction

1) Door frame: Use 2.5mm thickness Zinc galvanized steel, being painted under conditions of high temperature and static-free. There is brush seal inside the door frame.

2) Curtain material adopt high-density industrial fabric coating, 0.8mm thickness, yellow, blue, red, white, orange and other colors optional.

3) Transparent window, thickness is 0.8mm,size and location according to your order.

4. Open way

1) Radar

2) Pull rope

3) Push button

4) Loop detector

5) Remote control

5.Applicable areas

Airport, industry, carwash, Pharmaceutics&chemistry, Healthcare, Automotive, Food Industry, Distribution, Logistics, Cold stores & Refrigerators

6.Technical parameter

1) Opening & closing speed: 0.7-1.7m/s (optionally different opening speed upon

request)

2) Opening & closing frequency:1000-1500 times/day

3) Wind resistant capability:20m/s

7.Advantage

1)Convenience: High Speed Doors are designed for fast open and close, allowing

people and/or equipment to move quickly through the opening. Our automatic high

speed doors keep traffic flowing seamlessly, and even our manual high speed

doors operate more quickly than conventional doors.

2)Seal:ST High Speed Door install seal brush on both side of the dood guides,

make it dustproof, Wind resistant ,keep warm,noiseless aslo.

3)Safety system: high speed door use automatic bounce equipment,when the people or car touch the falling door, it bound up automatically;

At the bottom of our door, there are sensors. As you obstruct the infrared ray, the door will go up automatically.

High Speed Access. We offer a comprehensive range of high speed roller and high speed insulated doors for internal and external installations. High speed doors are ideal for high traffic areas where controlled access is required.

Save Energy & Reduce Contamination. Air leakage in industrial premises is a costly expense and ensuring you have the correct doors in operation is critical to reduce energy costs. The High speed automatic opening and closing of these rapid roll doors will provide valuable energy saving by maintaining the internal room temperature and also reduce contamination from airborne pollution and ingress of insects and vermin, essential in controlled warehouses and buildings. With a travel speed of up to 3 meters a second with some doors the operation cycle can be completed in a very short time, keeping the inside atmosphere as stable as possible all year round.

Access Control. Access control can be with remote control, radar sensors, ground loops, push button, key cards, digital code pads, finger readers and other devices to suit your individual needs in the warehouse or factory.

Door Structure

Workshop

Packaging

Certificates

Shenzhen Hongfa Automatic Co,.Ltd is a high-tech company that engages in the development of world-class advanced automatic doors. Our main products include quick rolling door, industrial accumulation door, industrial rolling door, PVC
rolling door, rapid rolling door, fire-resisting rolling door, industrial lift door, automatic induction door, automatic vertical hinged door, medical automatic door, stainless steel automatic door, electric folding gate, crystal rolling door, electric roller shutter of
various materials, and parking lot series.
